3000-5000L/H Auxiliary Boiler Parts Automatic Water Treatment Equipment
Contact Person : Swet Lee
Phone Number : +8618736903078
WhatsApp : +8618736903078
| Minimum Order Quantity : | 1 Set/Sets | Price : | Negotiation |
|---|---|---|---|
| Packaging Details : | The boiler in nude package, but covered with water-proof covering, accessories in plywood case or tin case, this can be changed as your requirements | Delivery Time : | 25-30 work days |
| Payment Terms : | L/C, D/A, D/P, T/T, Western Union, MoneyGram，Cash or on the basis of mutual agreement | Supply Ability : | 1500 Set/Sets Per Year |
| Place of Origin: | Henan China | Brand Name: | SWET |
|---|---|---|---|
| Certification: | ISO9001 | Model Number: | LDR0.05 -0.7-3010 |
|
Detail Information |
|||
| Rated Evaporation: | 50 Kg/h | Fixed Work Stress: | 0.7mpa |
|---|---|---|---|
| Input Power: | 36 KW | Output Current: | 55 A |
| Rated Voltage: | 220/380 V | Model: | LDR0.05 -0.7-3010 |
| Dimensions Length × Width × Height: | 900×650 ×1150 Mm | Weight: | 132 Kg |
| High Light: | industrial electric boiler,electric heating steam boiler |
||
Product Description
Product description
1. The water supply system is the throat of automatic steam generator, an endless supply of dry steam to users.
2. When the water source into the tank, turn on the power switch, driven by the automatic control signal, high temperature solenoid valve open, pump work, through the one-way valve injection furnace.
3. When the solenoid valve, one-way valve is blocked or damaged, when the water supply reaches a certain pressure will be over pressure valve overflow back to the tank, thus protecting the pump.
Product advantages
1. Intelligence,high configuration,security,convenience,reasonableness
2. Boiler can be continuous operation can also be timed to work, without special duty, usually just press the "start" button to boot, press the "stop" button to stop, very simple.
Application
1. Washing ironing industry
2. Food machinery industry
3. Biochemical industry
4. Other industries: (oil, automobile) steam cleaning industry
Product parameters
| model |
LDR0.004 -0.4 |
LDR0.013 -0.7 |
LDR0.024 -0.7 |
LDR0.035 -0.7 |
LDR0.05 -0.7 |
LDR0.08 -0.7 |
LDR0.1 -0.7 |
LDR0.15-0.7 | |
| project | unit | ||||||||
| Rated evaporation | Kg/h | 4 | 13 | 24 | 35 | 50 | 80 | 100 | 150 |
| Fixed work stress | Mpa | 0.4 | 0.7 | 0.7 | 0.7 | 0.7 | 0.7 | 0.7 | 0.7 |
|
Saturated steam temperature |
℃ |
151 |
171 | 171 | 171 | 171 | 171 | 171 | 171 |
| input power | KW | 3 | 9 | 18 | 24 | 36 | 54 | 72 | 108 |
| Output current | A | 6 | 14 | 27 | 41 | 55 | 79 | 113 | 164 |
| Rated voltage | V | 220/380 | 380 | 380 | 220/380 | 220/380 | 380 | 380 | 380 |
| Intake pipe diameter | DN | 15 | 15 | 15 | 15 | 15 | 15 | 15 | 15 |
| Main steam valve caliber | DN | 15 | 15 | 15 | 15 | 15 | 15 | 20 | 25 |
| Safety valve caliber | DN | 15 | 15 | 15 | 15 | 15 | 15 | 40 | 25 |
|
Dimensions |
mm |
680×520 ×850 |
750×550 ×920 |
850×600 ×1000 |
850×600 ×1000 |
900×650 ×1150 |
900×650 ×1200 |
880×870 ×1300 |
1010×740 ×1210 |
| weight | Kg | 50 | 79 | 92 | 118 | 132 | 150 | 280 | 160 |
