High efficiency 1.0 ton 0.7Mpa 1.0Mpa 1.2Mpa low pressure wood chip steam boiler for machinery industry
Contact Person : Swet Lee
Phone Number : +8618736903078
WhatsApp : +8618736903078
Minimum Order Quantity : | 1 Set/Sets | Price : | Negotiation |
---|---|---|---|
Packaging Details : | The biomass steam generator is covered with a waterproof film and the transport package is a wooden box. | Delivery Time : | 10-15 work days |
Payment Terms : | L/C, D/A, D/P, T/T, Western Union, MoneyGram | Supply Ability : | 1000 Set/Sets Per Year |
Place of Origin: | Henan China | Brand Name: | SWET |
---|---|---|---|
Certification: | ISO9001 | Model Number: | LSS0.3-0.7-S-3019 |
Detail Information |
|||
Rated Evaporation: | 300kg/h | Weight: | 1150kg |
---|---|---|---|
Style: | Vertical | Maximum Fuel Consumption(Kg/h): | 47 Kg/h |
Warranty: | 12months | Model Number: | LSS0.3-0.7-S-3019 |
Fuel: | Biomass,wood Pellet,straw | Usage: | Industrial,Other |
Rated Working Pressure: | 0.7-1.25MPa | Output: | Steam,Hot Water,Biomass |
Type: | Natural Circulation,Once Through | Working Pressure: | 0.4 / 0.7Mpa,0.4/0.7Mpa,High/medium Pressure,0.7---2.5Mpa,0.7Mpa |
Highlight: | industrial biomass boiler,small steam boiler |
Product Description
Product description
1. The steam boiler full automatic control. Just connect the water and electricity; press the key, then the boiler will automatically enter the automatic running, safer and more convenient.
2. Easy installation; no need to ask for a professional installation personnel to install, meanwhile saving a lot of installation materials.
Product advantages
1. Efficient and energy-saving: the use of three return design, the use of low cost, lower than the fuel (gas) to reduce operating costs of 30-70%;
2. Low-carbon environment: semi-gas combustion plus rear dust, soot, sulfur and nitrogen emissions low, low carbon dioxide emissions;
3. Simple operation: automatic feeding, ultra-low feeding, hopper to increase design, simple operation, small workload, single duty can be;
4. Safety: Thickening boiler steel, ultrasonic testing after strict testing; the use of electronic control, automatic adjustment of pressure water level, automatic heating and with water and overpressure protection
Installation requirements:
This section of the steam generator installed just connected to the water pipes, sewage pipes, steam pipes and exhaust pipes can be, waste heat recovery tank can be configured according to the needs of the company can be detailed installation of the video guidance of drawings at a glance, and readily available Install consulting services.
Application :
1. Washing ironing industry: dry cleaning machines, dryers, washing machines, dehydration machines, ironing machines, irons, and other equipment supporting the use of
2. Packaging machinery industry: labeling machine, sleeve labeling machine supporting the use
3. Biochemical industry: fermenter, reactor, sandwich pot, mixer, emulsifying machine and other equipment supporting the use of
4. Food machinery industry: tofu machine, steam box, sterilization tank, packaging machine, coating equipment, sealing machine, and other equipment supporting the use of
5. Other industries: (oil, automobile) steam cleaning industry, (hotels, dormitories, schools, mixing station) steam and hot water supply, (bridge, railway) concrete conservation
Generator product model | LHS0.1-0.7-S | LHS0.15-0.7-S | LSS0.2-0.7-S | LSS0.3-0.7-S | LSS0.4-0.7-S | YDZ0.5-0.7-S |
preset pressure(Mpa) | 0.7 | 0.7 | 0.7 | 0.7 | 0.7 | 0.7 |
Rated steam temperature(℃) | 170 | 170 | 170 | 170 | 170 | 170 |
Rated evaporation(Kg/h) | 100 | 150 | 200 | 300 | 400 | 500 |
Maximum fuel consumption(Kg/h) | 17 | 25 | 34 | 47 | 65 | 80 |
Thermal efficiency | 85% | 85% | 85% | 85% | 85% | 85% |
weight(Kg) | 600 | 700 | 1020 | 1150 | 1600 | 2700 |
Dimensions(Length × width × height)mm |
1600*900 *1900 |
1600*900 *1900 |
2150*950 *2400 |
2000*1400 *2700 |
2700*1100 *2450 |
2200*1500 *2500 |
