Single Drum Biomass Fired Hot Water Boiler , 20t / H Circulating Fluidized Bed Boiler

China Single Drum Biomass Fired Hot Water Boiler , 20t / H Circulating Fluidized Bed Boiler supplier
Single Drum Biomass Fired Hot Water Boiler , 20t / H Circulating Fluidized Bed Boiler supplier Single Drum Biomass Fired Hot Water Boiler , 20t / H Circulating Fluidized Bed Boiler supplier Single Drum Biomass Fired Hot Water Boiler , 20t / H Circulating Fluidized Bed Boiler supplier Single Drum Biomass Fired Hot Water Boiler , 20t / H Circulating Fluidized Bed Boiler supplier

Large Image :  Single Drum Biomass Fired Hot Water Boiler , 20t / H Circulating Fluidized Bed Boiler

Product Details:

Place of Origin: Henan China
Brand Name: SWET
Certification: ISO9001
Model Number: DHX20-1.25-0001

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set/Sets
Price: Negotiation
Packaging Details: 1. Industrial Steam Boiler in nude package. 2. All boiler accessories in plywood or wooden case. 3.Delivery Detail :Shipped in 60 days after payment
Delivery Time: shipped in 60 after payment
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram,Cash or on the basis of mutual agreement
Supply Ability: 700 Set/Sets Per Year
Contact Now
Detailed Product Description
Design Fuel: Coal Fuel,biomass Keywords: Industrial Steam Boiler
Item: DHX 20 TONS Color: Customer's Requirement
Thermal Efficiency: 91% Feed Water Temperature: 104℃
Model: DHX20-1.25 Company: China's First CFB Boiler Manufacture

20t / h Industrial Single Drum Biomass Fired Hot Water Circulating Fluidized Bed Boiler



Circulating fluidized bed boiler technology advantages



1. Circulating fluidized bed(CFB)boiler easy to achieve the comprehensive utilization of ash: Circulating fluidized bed(CFB)boiler excellent ashes conditions so that the furnace fuel low temperature burned, ash can be directly used for cement production, building materials.



2. Circulating fluidized bed(CFB)boiler lean combustion technology circulating fluidized bed boiler in the furnace by adding limestone, can be a simple desulfurization in the furnace, when the calcium and sulfur molar ratio of 2, the desulfurization efficiency can reach more than 84%, due to the operation of the use of graded air And low temperature combustion, so the amount of NOx generated very low. Thus greatly reducing SOx and NOx emissions, improve the atmosphere and environmental quality.



3. Circulating fluidized bed boiler could adopt various coal types and has high combustion efficiency, which is especially suitable for low quality, low calorific value coal.



Circular flow bed CFB boiler technical parameters:



Model Rated evaporation Work pressure Steam temperature Water supply temperature Fuel consumption Thermal efficiency Transport dimensions
Unit t/h MPa Kg/h % mm(Long x wide x high)
DHX20-1.25 20 1.25 194 104 2475 91 12000x8160x22120
DHX20-1.6 20 1.6 204 104 2483 91 12000x8160x22120
DHX20-2.5/400 20 2.5 400 104 2934 91 12000x8160x22120
DHX25-1.25 25 1.25 154 104 3003 91 13000x8610x23170
DHX25-1.6 25 1.6 204 104 3100 91 13000x8610x23170
DHX25-2.5/400 25 2.5 400 104 3692 93 13000x8610x23170
DHX30-1.25 30 1.25 194 104 3712 93 12170x9200x25500
DHX30-1.6 30 1.6 204 104 3724 93 12170x9200x25500
DHX30-2.5/400 30 2.5 400 104 4431 93 12170x9200x25500
DHX35-1.25 35 1.25 194 104 4331 91 13800x10320x26815

Circulating fluidized bed boiler working principle

Single Drum Biomass Fired Hot Water Boiler , 20t / H Circulating Fluidized Bed Boiler







Single Drum Biomass Fired Hot Water Boiler , 20t / H Circulating Fluidized Bed Boiler
