3 Ton Industrial Wood Boiler Biomass Steam Generator

Minimum Order Quantity : 1 Price : 35000USD-45100USD
Packaging Details : The boiler is covered with a waterproof film and the transport package is a wooden box. Delivery Time : 15-30 days after payment received
Supply Ability : 1500 sets per year
Place of Origin: Henan Province, China Brand Name: Swet
Certification: ISO9001 Model Number: YDZ3.0-0.7-S

Detail Information

Rated Evaporation: 3000kg/h Rated Pressure: 0.7Mpa
Rated Steam Temperature: 170℃ Boiler Evaporation: 1800000Kcal
Evaporation: 2100kw Fuel Consumption: 465kg/h
Thermal Efficiency: 93% Water Capacity: <29L
Length: 3300mm Width: 2700mm
Height: 3200mm The Calorific Value Of Biomass Particles: 4200Kcal/kg
Style: Horizontal Design Fuel: Biomass Fuel
Output: Steam
High Light:

Industrial Biomass Steam Generator


3000kg/h Industrial Wood Boiler


3000kg/h Biomass Steam Generator

Product Description

3 Ton Industrial Wood Boiler Biomass Steam Generator

Low costs, and environmental fuel combustion, clean and gasification automatic operation, simple operation, quick heating, hot enough, no chimney, low failure rate.
High efficient and energy-saving: thermal efficiency more than 90%, flue gas temperature to chimney less than 120 degrees Celsius.
Full automatic: user just starts the boiler with one-button, automatic ignition, automatic feeding, automatic temperature control, automatic start-stop cycle, automatic fault alarm etc.
Environmental protection: can be used in anywhere, even in the center of the city.
High safety, long life and high quality: Operating at atmospheric condition, without any dangers.
Self-cleaning and convenient maintenance. No need to install and easy to operate.
Steam boiler technical parameters
3 ton biomass steam boiler technical parameters
Rated evaporation 3000Kg/h
Model YDZ3.0-0.7-S
Rated pressure 0.7Mpa
Rated steam temperature 170℃
Design thermal efficiency 93%
Water capacity <29L
Fuel consumption 465kg/h
Approx dimensions L 3300mm
W 2700mm
H 3200mm
The calorific value of biomass particles 4200Kcal/kg
Note: Please contact us to confirm the relevant data before prefabrication, reservation and boiler room design.
3 Ton Industrial Wood Boiler Biomass Steam Generator
3 Ton Industrial Wood Boiler Biomass Steam Generator
Packaging & Shipping
3 Ton Industrial Wood Boiler Biomass Steam Generator
3 Ton Industrial Wood Boiler Biomass Steam Generator
Steam boiler applicable scenario
Widely used in plants greenhouses supply heating; Hotels, guesthouses, sauna bath center, beauty salon, villas, factories, schools and enterprises and institutions,scouring bath,heating and drying with hot water.
Especially suitable for garment ironing, chemical plating, hotel food.
Company Information
3 Ton Industrial Wood Boiler Biomass Steam Generator.png
Henan kaifeng Swet (original name Desheng) Boiler Co.Ltd was established in 1954 ,We have continued to provide customers with more than 60 years of quality service, known as the king of China's boiler. In 1987 China's first circulating fluidized bed boiler was born in our factory.
Any Question, Please contact us ,we serve you 24 hours !
3 Ton Industrial Wood Boiler Biomass Steam Generator
