100kg/H - 3000kg/H Wood Biomass Industrial Steam Boiler

Minimum Order Quantity : 1 SET Price : Negotiation
Packaging Details : biomass steam boiler body with plywood packaging. Delivery Time : 10 WORKING DAY
Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram Supply Ability : 3000 SETS PER YEAR
Place of Origin: HENAN,CHINA Brand Name: SWET
Certification: ISO9001 Model Number: YDZ

Detail Information

Product Name: Automatic 3000kg/h Wood Biomass Steam Boiler Item: YDZ- Biomass Steam Boiler
Design Fuel: Biomass Warranty: 12 Months
Thermal Efficiency: Over 92% The Biggest Fuel Consumption(Nm3/h): 70
Rated Evaporation (kg/h): 3000kg Rated Steam Temperature(℃): 170
Rated Steam Pressure(Mpa): 0.7 Size: 3200x1500x2100mm
Weight: 7200kg Type: Natural Circulation
High Light:

100kg/H Biomass Steam Boiler

,

3000kg/H Industrial Steam Boiler

,

Wood Biomass Industrial Steam Boiler

Product Description

Automatic 100kg/h to 3000kg/h wood biomass steam boiler

Product Description



1. Adopting negative pressure combustion method, unique primary air heating and secondary air combustion-assist configuration, make the combustion completely and no black smoke. The main body is arranged with multiple backhauls, the structure is compact, the heating surface is sufficient, and the pressure is very fast.





2. The water capacity is less than 30L, without the need for approval and inspection. The equipment adopts a fully automatic microcomputer control system, and the voltage is clear at a glance, which truly achieves the double insurance of the body control safety and the combustion system control safety.





3. The new water film dust collector and energy saver are integrated to greatly reduce the temperature of the flue gas and improve the thermal efficiency.





4. The whole machine leaves the factory for easy installation.



Lowest price 500kg biomass solid fuel steam boiler for business



100kg/H - 3000kg/H Wood Biomass Industrial Steam Boiler 1

3000kg solid fuel steam boiler core advantages:



1. High efficiency and energy saving: using renewable biomass energy as fuel, adopting vertical three-return design,


2. Fast gas production, low cost of use, 5 minutes of steam production



3. High-grade glass fiber silk multi-layer insulation, low heat loss, low energy consumption in built-in waste heat recovery

system, high thermal efficiency

.



100kg/H - 3000kg/H Wood Biomass Industrial Steam Boiler 2



100kg/H - 3000kg/H Wood Biomass Industrial Steam Boiler 3



100kg/H - 3000kg/H Wood Biomass Industrial Steam Boiler 4



100kg/H - 3000kg/H Wood Biomass Industrial Steam Boiler 5



100kg/H - 3000kg/H Wood Biomass Industrial Steam Boiler 6



100kg/H - 3000kg/H Wood Biomass Industrial Steam Boiler 7



The 100kg to 4000kg solid fuel steam boiler production process:



Lowest price 500kg biomass solid fuel steam boiler for business



The 500kg solid fuel steam boiler application area:

Lowest price 500kg biomass solid fuel steam boiler for business



Appliction field description:

1. For food industry: food factory, beverage factory, bakery, high temperature milk sterilization, steamed soy milk, steamed steamed buns.



2.For chemical industry: activated carbon heating and disinfection, high temperature plating.



3.For pharmaceutical industry: hospital disinfection, hospital canteen, hospital bath, pharmaceutical equipment heating, cooking medicine.





and so on...






Related Products









Lowest price 500kg biomass solid fuel steam boiler for business Lowest price 500kg biomass solid fuel steam boiler for business

Customer Access








FAQ





Q1:How to install a boiler?

A1:This boiler is factory-assembled and easy to install. It does not require professional installers to install, and it also saves a lot of installation materials.



Q2: How many years is the boiler’s life span?

A2: The boiler is designed for at least 10 years life span, but under good maintenance, usually the boiler can use at least 15 years, Swet Boiler provide full life after-sales service to each sold boiler.



Q3: How to choose a boiler model?

A3: Confirm the type (steam or hot water), capacity, working pressure (or output temperature) and fuel(coal, biomass, gas or oil or other fuel) of the boiler, Swet Boiler will suggest a suitable model based on your usage.



Q4: How is the warranty term?

A4: If any problems caused for quality during the warranty period, the Seller will repair or replace the broken parts for free, if the problem caused from the client’s side, the Seller will help supply the spare part at lowest cost.



Q5: How to get the best price quickly?

A5: We need to know the boiler capacity, the fuel you plan to use and the steam pressure you need, and then confirm the boiler model. (2) The customer needs to provide us with your name, e-mail address and company name, and we will send you a price list immediately. If you use WhatsApp, Skype or WeChat, you can provide us with your ID, which will be more convenient for our communication.



Q6: Why do you have to believe in the quality of our boilers?

A6:(1). Applied material information strength calculation report;

(2) Non-destructive testing (non-destructive testing) of steel plates, tubes, and electrodes is 100%;

(3) 100% X-ray inspection (welding): to ensure the quality of the entire boiler;

(4). Hydrostatic pressure test: ensuring standard working pressure and safety;

(5). Third party inspection report: Henan Boiler Testing Institute;

(6). Passed ISO:9001 and SGS certificates.



Sales and Service

Service characteristics:

Pre-sale technical guidance, including the host, auxiliary equipment selection and layout. Provide a full set of installation services, such as self-installation, can provide on-site technical guidance, including furnace wall masonry, cooking, commissioning and so on.

After the sale of professional and technical personnel to train the customer burner, until its complete grasp, independent operation. Usually 24 hours to accept telephone consultation, timely service.



100kg/H - 3000kg/H Wood Biomass Industrial Steam Boiler 12
