Energy Saving Portable Boiler , No Pollution 100 Kg/H-1000KG/H Industrial Steam Boiler
Contact Person : Swet Lee
Phone Number : +8618736903078
WhatsApp : +8618736903078
Minimum Order Quantity : | 1 Set/Sets | Price : | Negotiation |
---|---|---|---|
Packaging Details : | The boiler in nude package, but covered with water-proof covering, accessories in plywood case or tin case, this can be changed as your requirements | Delivery Time : | 25-30 work days |
Payment Terms : | L/C, D/A, D/P, T/T, Western Union, MoneyGram,Cash or on the basis of mutual agreement | Supply Ability : | 1500 Set/Sets Per Year |
Place of Origin: | Henan China | Brand Name: | SWET |
---|---|---|---|
Certification: | ISO9001 | Model Number: | LDR0.004 -0.4-3006 |
Detail Information |
|||
Rated Evaporation: | 4 Kg/h | Fixed Work Stress: | 0.4mpa |
---|---|---|---|
Saturated Steam Temperature: | 151℃ | Output Current: | 6A |
Rated Voltage: | 220/380V | Model: | LDR0.004 -0.4-3006 |
Dimensions Length × Width × Height: | 680×520 ×850mm | Weight: | 50Kg |
Highlight: | industrial electric steam generator,electric heating steam boiler |
Product Description
Product description
1. Boiler can be continuous operation can also be timed to work, without special duty, usually just press the "start" button to boot, press the "stop" button to stop, very simple.
2. Electric heating steam generator is mainly composed of water supply system, automatic control system, furnace and heating system and safety protection system.
3. Inspection-free small-sized electric steam boiler is a kind of mini boilers, small water tank, makeup water pump and control operating system that automatically replenish water, heat and generate low-pressure steam continuously without complicated installation
Product advantages
1. Automatic intelligent control technology, without special duty. Work flexible, can be set to manual or automatic mode.
2. With a full range of protection features, leakage protection, water protection, grounding protection, steam overpressure protection, over-current protection, power protection, etc., boiler automatic protection, safe home.
Application areas
Meat products factory, canning factory, winery, pharmaceutical factory, packing factory, building material factory, paint factory, beauty salon, bathing center, sauna, vegetable dehydration, steam room and so on.
Product parameters
model |
LDR0.004 -0.4 |
LDR0.013 -0.7 |
LDR0.024 -0.7 |
LDR0.035 -0.7 |
LDR0.05 -0.7 |
LDR0.08 -0.7 |
LDR0.1 -0.7 |
LDR0.15 -0.7 |
LDR0.17 -0.7 |
|
project | unit | |||||||||
Rated evaporation | Kg/h | 4 | 13 | 24 | 35 | 50 | 80 | 100 | 150 | 170 |
Fixed work stress | Mpa | 0.4 | 0.7 | 0.7 | 0.7 | 0.7 | 0.7 | 0.7 | 0.7 | 0.7 |
Saturated steam temperature | ℃ | 151 | 171 | 171 | 171 | 171 | 171 | 171 | 171 | 171 |
input power | KW | 3 | 9 | 18 | 24 | 36 | 54 | 72 | 108 | 120 |
Output current | A | 6 | 14 | 27 | 41 | 55 | 79 | 113 | 164 | 183 |
Rated voltage | V | 220/380 | 380 | 380 | 220/380 | 220/380 | 380 | 380 | 380 | 380 |
Intake pipe diameter | DN | 15 | 15 | 15 | 15 | 15 | 15 | 15 | 15 | 15 |
Main steam valve caliber | DN | 15 | 15 | 15 | 15 | 15 | 15 | 20 | 25 | 25 |
Safety valve caliber | DN | 15 | 15 | 15 | 15 | 15 | 15 | 40 | 25 | 25 |
Dimensions |
mm |
680× 520 ×850 |
750× 550 ×920 |
850× 600 ×1000 |
850× 600 ×1000 |
900× 650 ×1150
|
900× 650 ×1200 |
880× 870 ×1300 |
1010× 740 ×1210 |
1010× 740 ×1210 |
weight | Kg | 50 | 79 | 92 | 118 | 132 | 150 | 280 | 160 | 160 |
