0.3t/H 300kg Wood Fired Paddy Steam Boiler

Contact Now

0.3t/H 300kg Wood Fired Paddy Steam Boiler

Name: 0.3t/H 300kg Wood Fired Paddy Steam Boiler
Brand: Swet
SKU: YDZ0.3-0.7-S
Price: 7250 USD
Availability: InStock
Rating: 5 (181 reviews)

Minimum Order Quantity :	1	Price :	7250USD-8700USD
Packaging Details :	The boiler is covered with a waterproof film and the transport package is a wooden box.	Delivery Time :	15-30 days after payment received
Supply Ability :	1500 sets per year

Place of Origin:	Henan Province, China	Brand Name:	Swet
Certification:	ISO9001	Model Number:	YDZ0.3-0.7-S

Detail Information
Rated Evaporation:	300kg/h	Rated Pressure:	0.7Mpa
Rated Steam Temperature:	170℃	Thermal Efficiency:	93%
Water Capacity:	<29L	Length:	2400mm
Width:	1700mm	Height:	2100mm
Full Load Biomass Consumption:	46kg/h	Style:	Horizontal
Design Fuel:	Biomass Pellets	Evaporation:	210kw
Boiler Evaporation:	180000Kcal	Output:	Steam
The Calorific Value Of Biomass Pellets:	4200Kcal/kg	Shipping Weight:	3 Ton
Steam Outlet:	DN25	Water Intake:	DN25
Drain Valve:	DN25
High Light:	300kg Paddy Steam Boiler , 0.3t/H Paddy Steam Boiler , Biomass Pellets Fired Steam Boilers

Product Description

0.3t/h reliable performance 300kg wood fired paddy steam boiler for sale

Advanced steam boiler automatic controller, LCD screen, man-machine interface, users only need to set easily, the boiler can start and stop according to user requirements, load regulation, automatic water supply and other fully automatic operation. The boiler has complete functions, complete protection, simple operation, safe and reliable, and self-diagnosis function. Once an abnormal phenomenon occurs in the boiler operation, the combustion is automatically interrupted, and an audible and visual alarm is issued.

The boiler has strong adaptability to load. The well-designed built-in steam separator device meets the requirements of users for higher quality steam. The furnace body facilitates the cleaning of the inside of the furnace, which makes maintenance and maintenance extremely convenient.

Small steam boiler technical parameters

Fuel Cost analysis(Take 100 kg per hour as an example)
Equipment selection	Steam volume	Energy consumption	Unit Price	Operating costs
Electrothermal steam boiler	100kg	72 kw/h	0.08 USD/kw	10.91 USD
Fuel steam boiler	100kg	7 kg/h	0.53 USD/kg	7.42 USD
Gas steam boiler	100kg	8 m³/h natural gas	0.34 USD/m³	5.45 USD
Biomass steam boiler	100kg	20 kg/h wood pellet	0.08 USD/kg	3.03 USD

Biomass steam boiler technical
Rated evaporation	Rated pressure	Rated steam tempe rature	Feed water temper ature	Design thermal efficiency	Water capacity	Steam outlet	water intake	Drain valve	Dimensions			Shipping weight	Full load biomass consumption
Rated evaporation	Rated pressure	Rated steam tempe rature	Feed water temper ature	Design thermal efficiency	Water capacity	Steam outlet	water intake	Drain valve	L	W	H	Shipping weight	Full load biomass consumption
Kg/h	Mpa	℃	℃	%	L	DN	DN	DN	mm	mm	mm	T	kg/h
300	0.7	170	20	92%	<29	25	25	25	2400	1700	2100	3	46
400	0.7	170	20	92%	<29	32	25	25	2400	1700	2100	3.2	62
500	0.7	170	20	92%	<29	32	25	25	2500	1700	2600	4	77
700	0.7	170	20	92%	<29	40	25	25	2500	1700	2600	4.1	108
1000	0.7	170	20	92%	<29	50	25	25	2500	1700	2600	4.3	154

Rapid steam generation in five minutes, the thermal efficiency can reach more than 90%, the pressure is stable, and the running cost is low.

Low noise, low concentration of smoke and dust, no black smoke, fully in line with national first-class regional emission standards, environmentally friendly and reliable.

Fully automatic control system with automatic high and low water level protection, saving manpower.

The production process of our boiler

Small steam boiler applicable scenario

For food industry: food factory, beverage factory, bakery, high temperature milk sterilization, steamed soy milk, steamed steamed buns.

For pharmaceutical industry: hospital disinfection, hospital canteen, hospital bath, pharmaceutical equipment heating, cooking medicine.

For biological equipment industry: sterilizer, school laboratory, thermal test.

Our engineering case

Company Information

Henan kaifeng Swet (original name Desheng) Boiler Co.Ltd was established in 1954 ,We have continued to provide customers with more than 60 years of quality service, known as the king of China's boiler.

It’s the national designated A-class boilers and D1, D2 class pressure vessel manufacturing key enterprises and has passed ISO9001 international quality management certification system certification.

It holds level 1 boiler installation permit ,National special equipment manufacturing license ,National special equipment installation remould maintenance permits and so on.

In 1979 the world's first circulating fluidized bed boiler developed by the Austrian company in Finland.

In 1987 China's first circulating fluidized bed boiler was born in our factory.

In 2016 In order to meet current emissions and reduce energy consumption requirements, our company launched efficient low-emission energy-saving circulating fluidized bed boiler, has been identified by the national institute of special equipment.

OUR FACTORY

Our main products include circular fluidized bed (CFB) boilers, gas boilers, coal boilers, biomass boilers, oil boilers, power plant boilers, energy efficient boilers, slag boilers, efficient boilers, electric boilers, high pressure boilers, fully automatic Control of boilers, wood vapors biomass boilers, chain grate, condensing boilers, natural gas steam boilers, water pipe boilers, fire pipe boilers, all artificial intelligence boilers, biomass steam generators, refractory materials, boiler accessories and so on.

Packaging & Shipping

Our Customer Visit

FAQ

Q: How many years is the boiler’s life?

A: The boiler is designed for at least 20 years life.

Q: Can I get guarantee of products?

A: Yes, every product is 1 year quality warranty under customer correct using the products.

Q: How is the warranty term?

A: If any problems caused for quality during the warranty period, the Seller will repair or replace the broken parts for free, if the problem caused from the client’s side, the Seller will help supply the spare part at lowest cost.

Q: Do you have any Certificate?

A: Yes. Each of our boiler has China GB and ISO9001certificate

Q: How to install a boiler?

A: Our boiler provides completed installation drawing and manual, or send engineer abroad for installation guidance.

Q: What about the maintenance?

A: I will offer you the timely maintenance way sheet after installation of the boiler mainly parts.

Q: How to choose a boiler model?

A: Confirm the type (steam or hot water), capacity, pressure (or output temperature need) and fuel(coal, biomass, gas or oil) of the boiler, we will suggest a suitable model based on your usage.

Q: What about the production?

A: Produce time is 30 days.

Q: How can I pay you?

A: T/T is very well used. We also accept other ways, depending on the circumstances.

1) T/T with 30% deposit, when we sign the contract and the rest 70% should be paid by T/T before goods delivery from us. The payment accepted by our company's bank account are USD, RMB and Euro.
2) Alibaba Trade Assurance as the payment term with 30% deposit and 70% before shipment. The payment accepted by our Alibaba Trade Assurance account only for USD.

Any Question, Please contact us ,we serve you 24 hours !
