Fuel Gas 2t/H 0.7Mpa 1.0Mpa 1.2Mpa Fire Tube Industrial Steam Boiler For Paper Industry ISO9001 Approval
|
Product Details:
|
|
| Place of Origin: | Henan China |
|---|---|
| Brand Name: | SWET |
| Certification: | ISO9001 |
| Model Number: | WNS |
|
Payment & Shipping Terms:
|
|
| Minimum Order Quantity: | 1 Set/Sets |
| Price: | Negotiation |
| Packaging Details: | The boiler in nude package, but covered with water-proof covering, accessories in plywood case or tin case, this can be changed as your requirements |
| Delivery Time: | 25-30 work days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram，Cash or on the basis of mutual agreement |
| Supply Ability: | 1500 Set/Sets Per Year |
|
Detail Information |
|||
| Rated Evaporation: | 600kg / H | Rated Working Pressure: | 1.0/1.25/0.7 MPa |
|---|---|---|---|
| Rated Steam Temperature: | 184/194/204 ℃ | Feed Water Temperature: | 20 ℃ |
| Keywords: | Gas Steam Boiler | Model: | YDZ |
| Testing Efficiency: | 96.48 % | Color: | Customer Requirements |
| High Light: | industrial gas boiler,oil fired steam boiler |
||
Product Description
1.Environmental protection and durability: gas steam boiler with a new multi-tube cyclone dust collector and energy-saving integrated structure, greatly reducing the flue gas temperature, improve thermal efficiency, environmental protection requirements to meet the new national standards.
2.Sophisticated and beauty: gas steam boiler innovation and improvement to enhance the practicality, modeling novel, especially small size, easy to install without basic, product appearance, soft colors, and the environment coherent, full of artistic sense.
3.Easy installation; no need to ask for a professional installation personnel to install, meanwhile saving a lot of installation materials.
Gas steam boiler technical parameters
| Gas steam boiler technical parameter | |||||||||||||||
|
Rated evaporati on |
Rated pressure |
Rated steam temperat ure |
Feed water temperat ure |
Design thermal efficienc y |
Water capacit y |
Steam outlet |
water intake |
Drain valve |
Gas supply pressur e |
Gas pipe diamet er |
Dimensions |
Shippin g weight |
Full load biomas s consum ption |
||
| L | W | H | |||||||||||||
| Kg/h | Mpa | ℃ | ℃ | % | L | DN | DN | DN | Kpa | DN | mm | mm | mm | T | Nm³/h |
| 150 | 0.7 | 170℃ | 20℃ | 90% | 27 | 15 | 15 | 20 | 2-3.5 | 20 | 1250 | 1200 | 1700 | 0.7 | 11.7(NG) |
| 200 | 0.7 | 170℃ | 20℃ | 90% | 27.6 | 20 | 15 | 25 | 2-3.5 | 20 | 1600 | 1500 | 2300 | 1.2 | 15.7(NG) |
| 300 | 0.7 | 170℃ | 20℃ | 90% | 28 | 25 | 15 | 25 | 2-3.5 | 20 | 1700 | 1600 | 2300 | 2.3 | 22.3(NG) |
| 400 | 0.7 | 170℃ | 20℃ | 90% | 28 | 32 | 15 | 25 | 3.5-5 | 20 | 2350 | 1750 | 2200 | 2.8 | 30.5(NG) |
Gas steam boiler Fuel Cost analysis:
| Fuel Cost analysis(one hour) | ||||
| Equipment selection | Steam volume | Energy consumption | Unit Price | Operating costs |
| Electrothermal steam boiler | 100kg | 72 kw/h | 0.08 USD/kw | 10.91 USD |
| Fuel steam boiler | 100kg | 7 kg/h | 0.53 USD/kg | 7.42 USD |
| Gas steam boiler | 100kg | 8 m³/h natural gas | 0.34 USD/m³ | 5.45 USD |
| Biomass steam generator | 100kg | 20 kg/h wood pellet | 0.08 USD/kg | 3.03 USD |
gas steam boiler applicable scenario :
1.Textile industry: shrinking machine, dry cleaning machine, dryer, washing machine, dehydration machine, printing, ironing machine, iron and other equipment.
2.Other industries: automotive steam cleaning industry, hotels, hotels, schools, enterprises and other hot water supply, bridges, railway concrete conservation and other industries.
Our engineering case:
Henan Swet Boiler Co.Ltd was established in 1954 ,We have continued to provide customers with more than 60 years of quality service, known as the king of China's boiler.It’s the national designated A-class boilers and D1, D2 class pressure vessel manufacturing key enterprises and has passed ISO9001 international quality management certification system certification. It holds level 1 boiler installation permit ,National special equipment manufacturing license ,National special equipment installation remould maintenance permits and so on.In 1979 the world's first circulating fluidized bed boiler developed by the Austrian company in Finland, In 1987 China's first circulating fluidized bed boiler was born in our factory.
Our factory engineer with Tsinghua Thermal Engineering Department professor circulating fluidized bed boiler technology exchange.
OUR ADVANTAGES:
1.Chinese Academy of Sciences circulating fluidized bed boiler research and development base.
2.China 's top ten boiler manufacturing enterprises.
3.Shanghai Industrial Boiler Research Institute Industrial Boiler Technology Development Relying on the unit.
4.North China Water Conservancy and Hydropower University teaching and research base
5. The China’s first circular flow bed (CFB)boiler manufacturer
Some of our domestic customers:
China Petroleum Pipeline Materials and Equipment Corporation.
China Petroleum & Chemical Corporation.
China Aero Engine Group.
COFCO Group Limited.
