100kg to 3000kg 300000Kcal/h to 2000000Kcal/h wood pellet hot water boiler
Contact Person : Swet Lee
Phone Number : +8618736903078
WhatsApp : +8618736903078
| Minimum Order Quantity : | 1 Set/Sets | Price : | Negotiation |
|---|---|---|---|
| Packaging Details : | The boiler in nude package, but covered with water-proof covering, accessories in plywood case or tin case, this can be changed as your requirements | Delivery Time : | 25-30 work days |
| Payment Terms : | L/C, D/A, D/P, T/T, Western Union, MoneyGram，Cash or on the basis of mutual agreement | Supply Ability : | 1500 Set/Sets Per Year |
| Place of Origin: | Henan China | Brand Name: | SWET |
|---|---|---|---|
| Certification: | ISO9001 | Model Number: | QXS(SZS)4.2-1.6-Y,Q-3014 |
|
Detail Information |
|||
| Leaving Water Temperature: | 95(115)(130) ℃ | Efficiency: | 95.57 % |
|---|---|---|---|
| Model: | QXS(SZS)4.2-1.6-Y,Q-3014 | Keywords: | Hot Water Boiler |
| Rated Thermal Power: | 4.2 MW | Nominal Working Pressure: | 1.25(1.6) MPa |
| Highlight: | gas fired boiler,industrial water boiler |
||
Product Description
Product description
1. SZS-type oil-fired gas boiler is a dual-drum vertical type "D" type arrangement quick assembly water tube boiler
2. In order to ensure the ignition of the boiler, the top of the boiler is designed with explosion-proof door. Furnace with manhole, the boiler safe, reliable, and easy to maintain.
Product advantages
1. low power consumption
2. high thermal efficiency
3. good environmental protection effect
4. easy operation and good maintainability
5. convenient operation and convenient installation
Customer visit
1. China Petroleum Pipeline Materials and Equipment Corporation.
2. China Petroleum & Chemical Corporation.
3. China Aero Engine Group.
4. COFCO Group Limited.
Product parameters
|
SZS water pipe type full automatic gas-fired hot water energy-saving boiler |
|||||||
|
Model |
Rated thermal power |
nominal working pressure |
Leaving Water Temperature |
return water temperature |
efficiency |
gas consumption |
Overall dimensions of transportation |
|
Unit |
MW |
MPa |
℃ |
℃ |
% |
Nm³/h |
mm |
|
QXS(SZS)58 |
58 |
1.25(1.6)(2.5) |
130(150) |
70(90) |
98.3 |
6196 |
15360*7570*8318 |
|
QXS(SZS)48 |
48 |
1.25(1.6)(2.5) |
130(150) |
70(90) |
98.09 |
5048 |
15600*9500*7920 |
|
QXS(SZS)29 |
29 |
1.25(1.6) |
130(150) |
70(90) |
97.8 |
3150 |
9685*6870*7180 |
|
QXS(SZS)21 |
21 |
1.0(1.25)(1.6) |
115(130)(150) |
70(90) |
97.13 |
2328 |
10130*6170*6134 |
|
QXS(SZS)14 |
14 |
1.0(1.25)(1.6) |
115(130)(150) |
70(90) |
97.02 |
1558 |
8120*3385*3750 |
|
QXS(SZS)10.5 |
10.5 |
1.0(1.25)(1.6) |
115(130)(150) |
70(90) |
97 |
1136 |
7250*3682*3820 |
|
QXS(SZS)7 |
7 |
0.7(1.0)(1.25) |
95(115)(130) |
70(90) |
96.87 |
754 |
6770*3210*3775 |
|
QXS(SZS)7 |
7 |
1.25 |
115 |
70(90) |
95.76 |
763 |
6760*2780*3299 |
|
QXS(SZS)5.6 |
5.6 |
0.7(1.0)(1.25) |
95(115)(130) |
70(90) |
95.57 |
619.2 |
6450*2956*3620 |
|
QXS(SZS)4.2 |
4.2 |
0.7(1.0)(1.25) |
95(115)(130) |
70(90) |
95.36 |
456.7 |
5700*3105*3410 |
|
Performance features: symmetrical furnace, uniform distribution, good cooling, sufficient combustion, long service life, stable output |
|||||||
