Used in Poultry Farm 100Kg/h Diesel Oil Steam Generator Boiler
Contact Person : Swet Lee
Phone Number : +8618736903078
WhatsApp : +8618736903078
| Minimum Order Quantity : | 1 Set | Price : | Negotiation |
|---|---|---|---|
| Packaging Details : | Wood care plus tarpaulin packaging | Delivery Time : | 25-30 works day |
| Payment Terms : | L/C, D/A, D/P, T/T, Western Union, MoneyGram | Supply Ability : | 20000 Ton Per Year |
| Place of Origin: | Henan,China | Brand Name: | SWET |
|---|---|---|---|
| Certification: | ISO9001 | Model Number: | WNS |
|
Detail Information |
|||
| Rated Capacity: | 5.6MW | Working Pressure: | 0.7(1.0)(1.25)Mpa |
|---|---|---|---|
| Steam Temperature: | 95（115）（130）℃ | Feed Temperature: | 70℃ |
| Testing Efficiency: | 96.57% | Outline Dimension: | 5950*2556*3120mm |
| Usage: | Industrial | Structure: | Fire Tube,Water Tube |
| Pressure: | Low Pressure,High Pressure | Fuel: | Oil-fired,Gas-fired |
| Application: | Food,textile,School,Machinery Industry | ||
| High Light: | gas fired steam boiler,oil hot water boiler |
||
Product Description
Product Description
WNS series automatic fuel (gas) horizontal hot water boiler (utility model patent) adopts horizontal three-way wet back structure, which improves the boiler operating environment and improves the boiler combustion efficiency and service life.
The entire flue gas passage of the boiler is placed in the water, with a hot water tank in the tail and a well-designed thermal insulation outsourcing design. The smoke box seal adopts a labyrinth structure to avoid the occurrence of smoke leakage in the smoke box.
Technical Parameters
| Model | Unit | WNS5.6 |
| Rated capacity | MW | 5.6 |
| Working pressure | Mpa | 0.7(1.0)(1.25) |
| Steam temperature | ℃ | 95(115)(130) |
| Feed temperature | ℃ | 70 |
| Testing efficiency | ％ | 96.57 |
| Diesel consumption | Kg/h | 541.80 |
| Gas consumption | Nm³/h | 619.2 |
| Outline dimension | mm(L*W*H) | 5950*2556*3120 |
