100kg/H - 3000kg/H Wood Biomass Industrial Steam Boiler
Contact Person : Swet Lee
Phone Number : +8618736903078
WhatsApp : +8618736903078
| Minimum Order Quantity : | 1 Set/Sets | Price : | Negotiation |
|---|---|---|---|
| Packaging Details : | The steam boiler is covered with a waterproof film and the transport package is a wooden box. | Delivery Time : | 10-15 work days |
| Payment Terms : | L/C, D/A, D/P, T/T, Western Union, MoneyGram | Supply Ability : | 1000 Set/Sets Per Year |
| Place of Origin: | Henan China | Brand Name: | SWET |
|---|---|---|---|
| Certification: | ISO9001 | Model Number: | YDZ0.4-0.7-S |
|
Detail Information |
|||
| Rated Evaporation: | 400kg/h | Weight: | 3T |
|---|---|---|---|
| Preset Pressure: | 0.7mpa | Rated Steam Temperature: | 170℃ |
| Thermal Efficiency: | 93% | Color: | Customer's Requirement |
| Design Fuel: | Biomass | Warranty: | 12months |
| Usage: | Industrial,Garment Manufacturer | Type: | Natural Circulation,Once Through /Auxiliary Cycle,Natural Circulation/Once Through |
| Fuel: | Oil,Gas,Oil/Gas-fired | Style: | Horizontal,Vertical,horizontal And Vertical |
| Condition: | New | Output: | Steam |
| Pressure: | Low Pressure,High Pressure,Low Pressure(1.25MPa),Other | Structure: | Fire Tube,Water Tube,water-fire Tube |
| Application: | Industrial Production,Machinery Industry,Hospital,chemical Industry,Food Factory | Material: | Thicker Stainless Steel,Q345R Steel Plate,#20 Steel |
| Name: | Industry Fire Tube Boiler,gas Heating Boilers | Steam Temperature: | 170-204℃,194 ℃,184-225 Degree,≤194℃ |
| High Light: | natural gas steam boiler,industrial electric steam boiler |
||
Product Description
Environmentally friendly 400kg biomass hot water boiler for hotel
1. The inner tank adopts the international advanced three-return vertical water pipe tubular structure, the flue gas and the fin tube fully flush heat exchange, and the thermal efficiency reaches over 92%.
2. The boiler operating system is fully automatic, and all operating states can be seen at a glance in the LCD screen. You can observe the burner working status, boiler water level status, current temperature, feed pump running status, fault alarm status, etc. in the display, so that you can use it more safely.
400kg biomass hot water boiler core advantages:
1. Rapid steam generation in five minutes, the thermal efficiency can reach more than 90%, the pressure is stable, and the running cost is low.
1. Compact structure, small footprint, beautiful appearance, small investment in land engineering
2. Easy operation, stable operation, rapid steam generation, rapid steam generation within 5 minutes, high working efficiency and wide application
| Biomass steam boiler technical | |||||||||||||
| Rated evaporation | Rated pressure |
Rated steam tempe rature |
Feed water temper ature |
Design thermal efficiency | Water capacity | Steam outlet | water intake | Drain valve | Dimensions | Shipping weight | Full load biomass consumption | ||
| L | W | H | |||||||||||
| Kg/h | Mpa | ℃ | ℃ | % | L | DN | DN | DN | mm | mm | mm | T | Kg/h |
| 300 | 0.7 | 170℃ | 20℃ | 87% | 28 | 25 | 15 | 25 | 2000 | 1400 | 2700 | 1.35 | 49.3 |
| 600 | 0.7 | 170℃ | 20℃ | 93% | 29 | 32 | 15 | 25 | 2500 | 1800 | 2500 | 4.1 | 76.8 |
| 1000 | 0.7 | 170℃ | 20℃ | 92% | 29 | 32 | 15 | 25 | 3000 | 2300 | 2500 | 6 | 153.5 |
The 400kg biomass hot water boiler application area:
our engineering case:
