Efficient 100 Kg/H Electric Heating Steam Boiler , Fully Automatic Vertical Boiler

Product Details:
Place of Origin: Henan China
Brand Name: SWET
Certification: ISO9001
Model Number: LDR0.1 -0.7-3018
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set/Sets
Price: Negotiation
Packaging Details: The boiler in nude package, but covered with water-proof covering, accessories in plywood case or tin case, this can be changed as your requirements
Delivery Time: 25-30 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram,Cash or on the basis of mutual agreement
Supply Ability: 1500 Set/Sets Per Year

Detail Information

Rated Evaporation: 100 Kg/h Input Power: 72 KW
Output Current: 113 A Rated Voltage: 380 V
Model: LDR0.1 -0.7-3018 Dimensions Length × Width × Height: 880×870 ×1300 Mm
Weight: 280 Kg Safetyvalve Caliber: 40 DN
High Light:

industrial electric boiler

,

electric heating steam boiler

Product Description



Efficient and safe 100 kg/h Electric Steam Boiler with fully automatic


Product description

1. Electrical components are the core part of electric steam boiler.

2. The components of purchased electric appliances adopted by this product are both awarded "China Well-known Trademark", "China Famous Brand" Products and "3C Compulsory Certification Products"


Product advantages

1. Small scientific design

2. Unique internal structure design

3. One-stop electronic control system

4. Use of electricity is more environmentally friendly and more economical

Application

1. Oil, automobile

2. Steam cleaning industry

3. Hotels, dormitories, schools, mixing stations

4. Hot water supply, bridge, railway

5.  Concrete conservation, (casual beauty club) sauna bath, heat exchange equipment.



Product parameters


model

LDR0.004

-0.4

LDR0.013

-0.7

LDR0.024

-0.7

LDR0.035

-0.7

LDR0.05

-0.7

LDR0.08

-0.7

LDR0.1

-0.7

LDR0.15-0.7
project unit
Rated evaporation Kg/h 4 13 24 35 50 80 100 150
Fixed work stress Mpa

0.4

0.7 0.7 0.7 0.7 0.7 0.7 0.7
input power KW 3 9 18 24 36 54 72 108
Output current A 6 14 27 41 55 79 113 164
Rated voltage V 220/380 380 380 220/380 220/380 380 380 380
Intake pipe diameter DN 15 15 15 15 15 15 15 15

Main steam
valve caliber

DN 15 15 15 15 15 15 20 25
Safetyvalve caliber DN 15 15 15 15 15 15 40 25

Dimensions

mm

680×520

×850

750×550

×920

850×600

×1000

850×600

×1000

900×650

×1150

900×650

×1200

880×870

×1300

1010×740

×1210

weight Kg 50 79 92 118 132 150 280 160
