Vertical Double Drum Wood Pellet Fired Steam Boiler 83% Thermal Efficiency

Certification
Good quality Gas Steam Boiler for sales
Good quality Gas Steam Boiler for sales
We are very satisfied the machine, it's easy to assemble and operate. advanced controlling theory with high-performance PLC, high level of automatic.

—— Smith

During the three times cooperation, all the machines are working well, hope your company getting better and better. A good beginning is half done.

—— Abdul Moiz

I'm Online Chat Now

Vertical Double Drum Wood Pellet Fired Steam Boiler 83% Thermal Efficiency

China Vertical Double Drum Wood Pellet Fired Steam Boiler 83% Thermal Efficiency supplier
Vertical Double Drum Wood Pellet Fired Steam Boiler 83% Thermal Efficiency supplier Vertical Double Drum Wood Pellet Fired Steam Boiler 83% Thermal Efficiency supplier Vertical Double Drum Wood Pellet Fired Steam Boiler 83% Thermal Efficiency supplier

Large Image :  Vertical Double Drum Wood Pellet Fired Steam Boiler 83% Thermal Efficiency

Product Details:

Place of Origin: Henan China
Brand Name: SWET
Certification: ISO9001
Model Number: SZL20-1.6-T-0014

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set/Sets
Price: Negotiation
Packaging Details: The main part of the boiler is bare packaging and wood packaging, container or according to packaging needs.
Delivery Time: 25-35 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram,Cash or on the basis of mutual agreement
Supply Ability: 1500 Set/Sets Per Year
Contact Now
Detailed Product Description
Rated Evaporation: 20t/h Working Pressure: 1.6MPa
Return Water Temperature: 104℃ Keywords: Chain Grate Steam Boiler
Steam Temperature: 204℃ Boiler Dimensions: 15820x4620x8680mm
Combustion Mode: Suspension Combustion + Layer Combustion Thermal Efficiency: 83%

20T Industrial Vertical Double Drum Wood Pellet Biomass Steam Boiler



Structural Features



1. Efficient energy-saving structure of the body:



The boiler is a double-drum longitudinal type A type arrangement of fast-mounted water pipe steam boiler, the boiler assembled in the factory fast factory, single-layer layout, installation period is short, the installation of infrastructure costs low, is a more Good biomass steam boiler, its comprehensive performance indicators reached the advanced level of similar products in China.



2. High-quality boiler raw materials:



Boiler plate Chongqing Iron and Steel Company's products are the first national inspection-free products, set the pipe using Lu Baotie Steel's high-quality steel is a national excellent products, boiler tube Changzhou Steel Plant production of high-quality steel



3. Advanced boiler processing and testing equipment:



All the cutting of sheet metal cutting machine cutting, changing the original cut cutting the thermal effects of the drawbacks; Coil with a large four-stick bending machine, the cylinder processing quality more reliable;All the submerged arc welding with automatic welding, and the use of non-destructive testing, always control the quality of welding.



Technical Parameters



Boiler type and parameter list of double boiler barrel series chain grate boiler

Boiler model

Rated evaporation

Working pressure

Steam temperature

Water supply temperature

Exhaust temperature

Thermal efficiency

Boiler dimensions

Unit

t/h

Mpa

%

mm

SZL10-1.25-T

10

0.7/1.0/1.25

170/184/194

104

150

≥80

8830x3180x5730

SZL15-1.6-T

15

1.0/1.25/1.6

184/194/204

104

155

≥80

14000x4174x614

SZL20-1.6-T

20

1.0/1.25/1.6

184/194/204

104

155

≥80

15820x4620x8680

SZL25-2.5-T

25

1.25/1.6/2.5

194/204/224

104

160

≥80

12800x6000x8420

SZL30-2.5-T

30

1.25/1.6/2.5

194/204/224

104

160

≥80

13000x7100x9500

SZL35-2.5-T

35

1.25/1.6/2.5

194/204/224

104

160

≥80

3000x7600x9800
